Item # OS10S-S6Q8.3

ELCO PHOTOELECT SENSOR, OS10S-SERIES, OPPOSED, EMITTER, RED BEAM, OR:10 M, 10TO30VDC, -20TO60 DEG C, M8 3-PIN

  • $26.86 / EA
  • Manufacturer: ELCO
  • UM: EA
ELCO OPPOSED OR THROUGH BEAM TYPE PHOTOELECTRIC SENSORS CONSIST OF AN EMITTER AND RECEIVER. ONCE ALIGNED, ANY OBJECT THAT BLOCKS LIGHT OVER THE THRESHOLD WILL TRIGGER THE DEVICE. BECAUSE OF THIS, THEY ARE HIGHLY SENSITIVE, CAN HAVE VERY LONG SENSING RANGES, CAN DETECT SMALL OBJECTS WHILE BEING RESISTANT TO DUST AND DEBRIS. THEY ARE PERFECT FOR APPLICATIONS THAT REQUIRE PRECISE OBJECT DETECTION USING LIGHT SIGNALS - REGARDLESS OF WHETHER YOU WANT TO DETECT TRANSPARENT, SHINY OR COLORED OBJECTS.
SPECIFICATIONS
EMITTER TYPE:
OPPOSED
LIGHT TYPE:
RED BEAM
OPERATING RANGE:
10M
CABLE:
NONE
CONNECTOR:
M8 4-PIN CONNECTOR
TEMPERATURE RANGE:
-20 TO 60 DEG C
SERIES:
OS10S SERIES
VOLTAGE RANGE:
10 TO 30VDC
SAFETY RATING:
IP67

NOT FINDING WHAT YOU NEED?
SEND US AN E-MAIL:
SALES@THEPNEUMATICSTORE.COM

OS10S-S6Q8.3 ELCO PHOTOELECT SENSOR, OS10S-SERIES, OPPOSED, EMITTER, RED BEAM, OR:10 M, 10TO30VDC, -20TO60 DEG C, M8 3-PIN
OS10S-S6Q8.3 ELCO PHOTOELECT SENSOR, OS10S-SERIES, OPPOSED, EMITTER, RED BEAM, OR:10 M, 10TO30VDC, -20TO60 DEG C, M8 3-PIN
OS10S-S6Q8.3 ELCO PHOTOELECT SENSOR, OS10S-SERIES, OPPOSED, EMITTER, RED BEAM, OR:10 M, 10TO30VDC, -20TO60 DEG C, M8 3-PIN
Click image to enlarge
OS10S-S6Q8.3 ELCO PHOTOELECT SENSOR, OS10S-SERIES, OPPOSED, EMITTER, RED BEAM, OR:10 M, 10TO30VDC, -20TO60 DEG C, M8 3-PIN
OS10S-S6Q8.3 ELCO PHOTOELECT SENSOR, OS10S-SERIES, OPPOSED, EMITTER, RED BEAM, OR:10 M, 10TO30VDC, -20TO60 DEG C, M8 3-PIN
OS10S-S6Q8.3 ELCO PHOTOELECT SENSOR, OS10S-SERIES, OPPOSED, EMITTER, RED BEAM, OR:10 M, 10TO30VDC, -20TO60 DEG C, M8 3-PIN

Specifications

EMITTER TYPE OPPOSED
LIGHT TYPE RED BEAM
OPERATING RANGE 10M
CABLE NONE
CONNECTOR M8 4-PIN CONNECTOR
TEMPERATURE RANGE -20 TO 60 DEG C
SERIES - BODY SIZE OS10S SERIES

Item # OS10S-S6Q8.3

ELCO PHOTOELECT SENSOR, OS10S-SERIES, OPPOSED, EMITTER, RED BEAM, OR:10 M, 10TO30VDC, -20TO60 DEG C, M8 3-PIN

  • $26.86 / EA
    • Log in to see if custom discounts apply

    Documents

    OS10S-S6Q8.3 ELCO PHOTOELECT SENSOR, OS10S-SERIES, OPPOSED, EMITTER, RED BEAM, OR:10 M, 10TO30VDC, -20TO60 DEG C, M8 3-PIN
    OS10S-S6Q8.3 ELCO PHOTOELECT SENSOR, OS10S-SERIES, OPPOSED, EMITTER, RED BEAM, OR:10 M, 10TO30VDC, -20TO60 DEG C, M8 3-PIN
    OS10S-S6Q8.3 ELCO PHOTOELECT SENSOR, OS10S-SERIES, OPPOSED, EMITTER, RED BEAM, OR:10 M, 10TO30VDC, -20TO60 DEG C, M8 3-PIN
