Item # OS22-SS6
ELCO PHOTOELECT SENSORS, OS22-SERIES, OPPOSED, EMITTER, POINT LIGHT, OR:1 M, 10TO30VDC, -10TO50 DEG C, CABLE 2M
- $15.50 / EA
- Manufacturer: ELCO
- UM: EA
ELCO OPPOSED OR THROUGH BEAM TYPE PHOTOELECTRIC SENSORS CONSIST OF AN EMITTER AND RECEIVER. ONCE ALIGNED, ANY OBJECT THAT BLOCKS LIGHT OVER THE THRESHOLD WILL TRIGGER THE DEVICE. BECAUSE OF THIS, THEY ARE HIGHLY SENSITIVE, CAN HAVE VERY LONG SENSING RANGES, CAN DETECT SMALL OBJECTS WHILE BEING RESISTANT TO DUST AND DEBRIS. THEY ARE PERFECT FOR APPLICATIONS THAT REQUIRE PRECISE OBJECT DETECTION USING LIGHT SIGNALS - REGARDLESS OF WHETHER YOU WANT TO DETECT TRANSPARENT, SHINY OR COLORED OBJECTS.
| SPECIFICATIONS | |
|---|---|
| EMITTER TYPE: | |
| LIGHT TYPE: | |
| OPERATING RANGE: | |
| CABLE: | |
| CONNECTOR: | |
| TEMPERATURE RANGE: | |
| SERIES: | |
| VOLTAGE RANGE: | |
| SAFETY RATING: | |
NOT FINDING WHAT YOU NEED?
SEND US AN E-MAIL:
SALES@THEPNEUMATICSTORE.COM
Click image to enlarge
Specifications
| EMITTER TYPE | OPPOSED |
| LIGHT TYPE | POINT LIGHT |
| OPERATING RANGE | 1M |
| CABLE | 2M CABLE |
| CONNECTOR | NONE |
| TEMPERATURE RANGE | -10 TO 50 DEG C |
| SERIES - BODY SIZE | OS22 SERIES |
Item # OS22-SS6
ELCO PHOTOELECT SENSORS, OS22-SERIES, OPPOSED, EMITTER, POINT LIGHT, OR:1 M, 10TO30VDC, -10TO50 DEG C, CABLE 2M
Documents
×
