Item # OS4-AK15LP6
ELCO PHOTOELECT SENSOR, OS4-SERIES, DIFF FIXED BGS, RED BEAM, OR:4-15MM, PNP, LO, -10TO55 DEG C, SW FRQ:800HZ, CABLE 2M
- $35.03 / EA
- Manufacturer: ELCO
- UM: EA
DIFFUSE PHOTOELECTRIC SENSORS EMIT LED LIGHT AND ARE ABEL TO DISTINGUISH BETWEEN AN OBJECT MOVING IN FRONT OF IT AND THE BACKGROUND (FOR EXAMPLE A CONVEYOR BELT WITH BOXES MOVING ALONG IT). THIS IS DONE BY USING 2 PHOTODIODES PROGRAMMED TO TRIGGER WHEN THE MANUALLY SET THRESHOLDS HAVE BEEN SET. THRESHOLDS ARE OFTEN SET BY A MECHANICAL DIAL LOCATED ON THE SENSOR HOUSING.
ELCO OS4 SERIES HAS A THIN DESIGN, MAKING IT VERY SUITABLE FOR LIMITED MOUNTING SPACE REQUIREMENTS IN ELECTRONIC, SEMICONDUCTOR AND OTHER INDUSTRIES. BGS PRODUCTS HAVE EXCELLENT BLACK-AND-WHITE ATTENUATION CHARACTERISTICS, SUITABLE FOR DETECTING NON-BRIGHT SURFACE OBJECTS.
- SERIES DETAILS
- 2 MM MOUNTING HOLE
- BUILT IN METAL PARTS
- STURDY DESIGN AND A LONG LIFETIME
- SMALL RED BEAM VCSEL LASER
- IP67 SAFFETY RATING
| SPECIFICATIONS | |
|---|---|
| BEAM TYPE: | |
| OUTPUT: | |
| INDICATOR: | |
| OPERATING VOLTAGE: | |
| OPERATING RANGE: | |
| TEMPERATURE RANGE: | |
| SWITCHING FREQUENCY: | |
| CABLE: | |
| CONNECTOR: | |
| OPTIONS: |
NOT FINDING WHAT YOU NEED?
SEND US AN E-MAIL:
SALES@THEPNEUMATICSTORE.COM
Specifications
| LIGHT TYPE | RED BEAM |
| OUTPUT | PNP |
| INDICATOR | L.O |
| OPERATING RANGE | 4 TO 15MM |
| CABLE | 2M CABLE |
| CONNECTOR | NONE |
| OPTIONS | BACKGROUND SUPPRESSION |
Item # OS4-AK15LP6
ELCO PHOTOELECT SENSOR, OS4-SERIES, DIFF FIXED BGS, RED BEAM, OR:4-15MM, PNP, LO, -10TO55 DEG C, SW FRQ:800HZ, CABLE 2M
Documents
