Item # OS4-K30DP6

ELCO PHOTOELECT SENSOR, OS4-SERIES, DIFF FIXED, RED BEAM, OR:1-30MM, PNP, DO, 10TO30VDC, -10TO55 DEG C, SW FRQ:800HZ, CABLE 2M

  • $35.03 / EA
  • Manufacturer: ELCO
  • UM: EA

ELCO DIFFUSED PHOTOELECTRIC SENSORS EMIT LED LIGHT AND IF THE DEVICE RECEIVES REFLECTED LIGHT IT IS TRIGGERED. THEY OFFER A HIGH LEVEL OF RELIABILITY TO DETECT OBJECTS WITHIN THE DETECTION RANGE. THEY'RE INCREDIBLY SIMPLE TO ALIGN, SMALL INSTALLATION SPACE REQUIRED, AND HAVE A STRONG RESILIENCE TO THE OBJECT COLOR, SHAPE, AND AMBIENT LIGHT.

SPECIFICATIONS
SENSOR - LIGHT TYPE:
DIFFUSED FIXED-RED BEAM
OPERATING RANGE:
1 TO 30MM
OUTPUT:
PNP - D.O
SWITCHING FREQ:
800HZ
CABLE:
2M CABLE
CONNECTOR:
NONE
SERIES:
OS4 SERIES
VOLTAGE RANGE:
10-30VCD
TEMPERATURE RANGE:
-10 TO 55 DEG C
SAFETY RATING:
IP67

NOT FINDING WHAT YOU NEED?
SEND US AN E-MAIL:
SALES@THEPNEUMATICSTORE.COM

OS4-K30DP6 ELCO PHOTOELECT SENSOR, OS4-SERIES, DIFF FIXED, RED BEAM, OR:1-30MM, PNP, DO, 10TO30VDC, -10TO55 DEG C, SW FRQ:800HZ, CABLE 2M
OS4-K30DP6 ELCO PHOTOELECT SENSOR, OS4-SERIES, DIFF FIXED, RED BEAM, OR:1-30MM, PNP, DO, 10TO30VDC, -10TO55 DEG C, SW FRQ:800HZ, CABLE 2M
OS4-K30DP6 ELCO PHOTOELECT SENSOR, OS4-SERIES, DIFF FIXED, RED BEAM, OR:1-30MM, PNP, DO, 10TO30VDC, -10TO55 DEG C, SW FRQ:800HZ, CABLE 2M
OS4-K30DP6 ELCO PHOTOELECT SENSOR, OS4-SERIES, DIFF FIXED, RED BEAM, OR:1-30MM, PNP, DO, 10TO30VDC, -10TO55 DEG C, SW FRQ:800HZ, CABLE 2M
Click image to enlarge
OS4-K30DP6 ELCO PHOTOELECT SENSOR, OS4-SERIES, DIFF FIXED, RED BEAM, OR:1-30MM, PNP, DO, 10TO30VDC, -10TO55 DEG C, SW FRQ:800HZ, CABLE 2M
OS4-K30DP6 ELCO PHOTOELECT SENSOR, OS4-SERIES, DIFF FIXED, RED BEAM, OR:1-30MM, PNP, DO, 10TO30VDC, -10TO55 DEG C, SW FRQ:800HZ, CABLE 2M
OS4-K30DP6 ELCO PHOTOELECT SENSOR, OS4-SERIES, DIFF FIXED, RED BEAM, OR:1-30MM, PNP, DO, 10TO30VDC, -10TO55 DEG C, SW FRQ:800HZ, CABLE 2M
OS4-K30DP6 ELCO PHOTOELECT SENSOR, OS4-SERIES, DIFF FIXED, RED BEAM, OR:1-30MM, PNP, DO, 10TO30VDC, -10TO55 DEG C, SW FRQ:800HZ, CABLE 2M

Specifications

LIGHT TYPE RED BEAM
OUTPUT PNP
INDICATOR D.O
OPERATING RANGE 1 TO 30MM
CABLE 2M CABLE
CONNECTOR NONE
OPTIONS NONE
