Item # OSM42-KL2000C2B6

ELCO DISTANCE SENSOR(TRI), OSM42-SERIES, RED LASER, OR:150-2000MM, RES: 1MM, 2 X PUSH-PULL, TEACH BUTTON, 10-30VDC, 2 M CABLE

  • $222.33 / EA
  • Manufacturer: ELCO
  • UM: EA

TRIANGULATION LASER DISTANCE SENSORS USE A RED LASER TO EMITTED A PULSE FROM THE SENSOR, REFLECTED OFF THE TARGET OBJECT AND TRAVELS BACK THROUGH THE RECEIVING LENS BEFORE BEING DETECTED BY THE CMOS LIGHT SENSOR. THE DISTANCE FROM THE SENSOR TO THE OBJECT IS CALCULATED BY DETERMINING WHERE THE HIGHEST INTENSITY OF LIGHT IS RECEIVED ALONG THE CMOS. THIS METHOD OF LASER DISTANCE MEASURMENT MEANS SMALLER DETECTION WINDOWS WITH HIGHER DEGREES OF ACCURACY.

SPECIFICATIONS
OPERATING RANGE:
150-2000MM
RESOLUTION:
1MM
OUTPUT:
2 X PUSH-PULL
OUTPUT OPTION:
TEACH BUTTON
OPERATING VOLTAGE:
10-30VDC
CONNECTOR:
2M CABLE
TEMPERATURE RANGE:
-10 TO 50 DEG C

NOT FINDING WHAT YOU NEED?
SEND US AN E-MAIL:
SALES@THEPNEUMATICSTORE.COM

OSM42-KL2000C2B6 ELCO DISTANCE SENSOR(TRI), OSM42-SERIES, RED LASER, OR:150-2000MM, RES: 1MM, 2 X PUSH-PULL, TEACH BUTTON, 10-30VDC, 2 M CABLE
OSM42-KL2000C2B6 ELCO DISTANCE SENSOR(TRI), OSM42-SERIES, RED LASER, OR:150-2000MM, RES: 1MM, 2 X PUSH-PULL, TEACH BUTTON, 10-30VDC, 2 M CABLE
OSM42-KL2000C2B6 ELCO DISTANCE SENSOR(TRI), OSM42-SERIES, RED LASER, OR:150-2000MM, RES: 1MM, 2 X PUSH-PULL, TEACH BUTTON, 10-30VDC, 2 M CABLE
Click image to enlarge
OSM42-KL2000C2B6 ELCO DISTANCE SENSOR(TRI), OSM42-SERIES, RED LASER, OR:150-2000MM, RES: 1MM, 2 X PUSH-PULL, TEACH BUTTON, 10-30VDC, 2 M CABLE
OSM42-KL2000C2B6 ELCO DISTANCE SENSOR(TRI), OSM42-SERIES, RED LASER, OR:150-2000MM, RES: 1MM, 2 X PUSH-PULL, TEACH BUTTON, 10-30VDC, 2 M CABLE
OSM42-KL2000C2B6 ELCO DISTANCE SENSOR(TRI), OSM42-SERIES, RED LASER, OR:150-2000MM, RES: 1MM, 2 X PUSH-PULL, TEACH BUTTON, 10-30VDC, 2 M CABLE

Specifications

OPERATING RANGE 150-2000MM
RESOLUTION 1MM
OUTPUT 2 X PUSH-PULL
OUTPUT OPTIONS TEACH BUTTON
OPERATING VOLTAGE 10-30VDC
CONNECTOR 2M CABLE
SERIES - BODY SIZE OSM42 SERIES

Item # OSM42-KL2000C2B6

ELCO DISTANCE SENSOR(TRI), OSM42-SERIES, RED LASER, OR:150-2000MM, RES: 1MM, 2 X PUSH-PULL, TEACH BUTTON, 10-30VDC, 2 M CABLE

  • $222.33 / EA
    • Log in to see if custom discounts apply

    Documents

    OSM42-KL2000C2B6 ELCO DISTANCE SENSOR(TRI), OSM42-SERIES, RED LASER, OR:150-2000MM, RES: 1MM, 2 X PUSH-PULL, TEACH BUTTON, 10-30VDC, 2 M CABLE
    OSM42-KL2000C2B6 ELCO DISTANCE SENSOR(TRI), OSM42-SERIES, RED LASER, OR:150-2000MM, RES: 1MM, 2 X PUSH-PULL, TEACH BUTTON, 10-30VDC, 2 M CABLE
    OSM42-KL2000C2B6 ELCO DISTANCE SENSOR(TRI), OSM42-SERIES, RED LASER, OR:150-2000MM, RES: 1MM, 2 X PUSH-PULL, TEACH BUTTON, 10-30VDC, 2 M CABLE
